夾套保溫截止閥
| 產品型號 Production type |
閥體.閥蓋 Body bonnet |
閥瓣Dise | 填料Packing |
| BJ45W-25P BJ45W-40P BJ45W-64P |
ZG1Cr18Nl9Ti | 1Cr18Ni9Ti | PTFT |
| 聚四氟乙烯 | |||
| BJ45W-25P（R） BJ45W-40P BJ45W-64P |
ZG1Cr18Ni12Mo2Ti | 1Cr18ni12Mo2Ti | PTFE |
| 聚四氟乙烯 |
主要性能規范
| 型號 TYPE |
公稱壓力 Nominal pressure PN（MPa） |
試驗壓力 Test pressure（MPa） | 適用溫度 Applicable temperature |
適用介質 Applicable medium |
保溫套壓力 Jacket pressure |
|
| shell | seal | |||||
| BJ45W-25P | 2.5 | 3.75 | 2.75 | ≤200 | Acetic urea 1 |
≤1.3 |
| BJ45W-40P | 4.0 | 6.0 | 4.4 | |||
| BJ45W-64P | 6.4 | 9.0 | 6.6 | |||
| BJ45W-25P | 2.5 | 3.75 | 2.75 | Acetic urea | ||
| BJ45W-40P | 4.0 | 6.0 | 4.4 | |||
| BJ45W-64P | 6.4 | 9.0 | 6.6 | |||
主要連接尺寸和外形尺寸
| 公稱壓力 Nominal pressure |
公稱通徑DN(mm) Nominal Diameter |
尺寸 Dimensions | |||||||||||||
| L | D | D1 | D2 | D3 | b1 | F0 | b | D6 | 3-G | Z- d | H | H1 | D0 | ||
|
2.5 4.0 |
15 | 170 | 105 | 75 | 55 | 35 | 8 | 4 | 16 | 51 | 3/8 | 4-Φ14 | 250 | 262 | 120 |
| 20 | 190 | 115 | 115 | 65 | 42 | 8 | 4 | 16 | 58 | 3/8 | 4-Φ14 | 292 | 308 | 140 | |
| 25 | 210 | 135 | 135 | 78 | 50 | 8 | 4 | 18 | 66 | 3/8 | 4-Φ18 | 340 | 375 | 160 | |
| 32 | 230 | 145 | 145 | 85 | 60 | 8 | 4 | 18 | 76 | 3/8 | 4-Φ18 | 338 | 375 | 160 | |
|
2.5 4.0 |
40 | 260 | 160 | 125 | 100 | 72 | 8 | 4 | 20 | 65 | 1/2 | 4-Φ18 | 360 | 386 | 160 |
| 50 | 300 | 180 | 145 | 120 | 94 | 8 | 4 | 22 | 88 | 1/2 | 8-Φ18 | 410 | 450 | 240 | |
| 65 | 340 | 195 | 160 | 130 | 105 | 8 | 4 | 22 | 110 | 1/2 | 8-Φ18 | 440 | 485 | 240 | |
| 80 | 380 | 230 | 190 | 160 | 128 | 11 | 4.5 | 24 | 121 | 1/2 | 8-Φ23 | 540 | 600 | 280 | |
| 100 | 430 | 270 | 220 | 188 | 154 | 11 | 4.5 | 28 | 150 | 1/2 | 8-Φ25 | 560 | 625 | 320 | |
| 125 | 300 | 250 | 218 | 182 | 11 | 4.5 | 30 | 176 | 1/2 | 8-Φ25 | 625 | 737 | 360 | ||
| 150 | 550 | 330 | 280 | 248 | 2 | 11 | 4 | 32 | 204 | 1/2 | 12-Φ25 | 720 | 790 | 360 | |
| 6.4 | 25 | 235 | 160 | 125 | 8 | 50 | 8 | 4 | 22 | 1/2 | 4-Φ18 | 375 | 375 | 160 | |
| 32 | 260 | 165 | 125 | 88 | 60 | 8 | 4 | 24 | 1/2 | 4-Φ23 | 383 | 383 | 160 | ||
| 50 | 300 | 200 | 160 | 130 | 4 | 26 | 110 | 1/2 | 8-Φ23 | 450 | 450 | 240 | |||
| 65 | 340 | 210 | 170 | 140 | 4.5 | 30 | 121 | 1/2 | 8-Φ23 | 510 | 510 | 240 | |||
| 100 | 430 | 270 | 220 | 188 | 154 | 154 | 4.5 | 36 | 1/2 | 8-Φ25 | 670 | 670 | 400 | ||
| 100 | 415 | 300 | 250 | 218 | 32 | 1/2 | 8-Φ25 | 670 | 670 | 400 | |||||
訂購注意事項：
夾套保溫截止閥產品電子樣本所涵蓋的參數表、性能表、尺寸表、圖片、文字描述等信息，僅為上海依耐夾套保溫截止閥說明書的一部分，供選型參考之用，詳細產品說明書、以及CAD圖紙、安裝圖、尺寸圖等請來電索取。由于編輯水平有限，錯誤和不妥之處在所難免，真誠希望您批評指正。
